Musway NX700.3

Name: Musway NX700.3
Brand: Musway
SKU: NX700.3
Price: 549.95 USD
Availability: InStock

In Stock

NX Series 3-Channel 150W RMS x 2 + 3rd Sub Channel 425W RMS x1 at 2 Ohm, Class-D Full Range Micro Car Amplifier with Remote Bass Control Included

Part No.-NX700.3

$549.95

30 Days Returns Accepted.
Lifetime Tech Support Included.
Free Shipping up to $45.

Reserve Yours Now

Reserve yours from the next batch. Charged at checkout, shipped in order received.

Out of stock

One email the moment stock lands, nothing else.
Waitlist is notified in the order it was joined.
Unsubscribe from the email itself, one click.

SKU :NX700.3

Brand :Musway

Fit Guide. Check if it will fit your car.
We Price Match! Call Us! +1 (310) 594-8918

Musway NX700.3 NX Series 3-Channel 150W RMS x 2 + 3rd Sub Channel 425W RMS x1 at 2 Ohm, Class-D Full Range Micro Car Amplifier with Remote Bass Control Included - German Engineered

We are a Musway authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!

What's Inside?

• 3-Channel Class-D Full Range Micro Car Amplifier
• Remote Bass Control
• Owner's Manual

Compact 3-Channel Class D Power with Flexible Performance

This micro 3-channel Class D amplifier (89 × 41 × 168mm) delivers powerful, high-fidelity sound while fitting discreetly in tight vehicle spaces. Channels 1/2 provide 85W x 2 at 4Ω or 150W x 2 at 2Ω, with the option to bridge for 300W, while the sub channel delivers 250W at 4Ω or 425W at 2Ω. With a wide 4–50,000Hz frequency response (@ -3dB), it ensures clean, detailed audio across the full spectrum.

Crystal-Clear Sound with Advanced Control

Enjoy pristine audio with a >99dB signal-to-noise ratio and ultra-low distortion (THD+N <0.02% @ 5W). Advanced filtering lets you fine-tune your system: Channels 1/2 feature adjustable low/high-pass filters (20–400Hz), while the sub channel includes low-pass (50–250Hz), subsonic (10–50Hz), and bass boost (0–18dB). Designed for modern vehicles, it supports start-stop systems, high-level input via EPS cable, and auto turn-on for seamless, hassle-free operation.

Convenient Bass Control with Safe and Reliable Operation

Fine-tune your subwoofer output on the fly with the included remote bass controller for precise, effortless adjustments. Designed for safety and reliability, the amplifier operates on 10.5–16.5V (momentarily down to 7V) and requires a 60A external fuse for protection.

Compact 3-Channel Class D Power: Digital Class D design in a micro chassis (89 x 41 x 168 mm) for hidden installations
Flexible Output: Channels 1/2: 2 x 85W @ 4Ω, 2 x 150W @ 2Ω, bridged 1 x 300W; Sub: 1 x 250W @ 4Ω, 1 x 425W @ 2Ω
Wide Frequency Response: 4 – 50,000 Hz (@ -3 dB) with high-fidelity reproduction
Clean Sound: >99 dB signal-to-noise ratio, THD+N < 0.02% @ 5 W
Advanced Filtering: CH1/CH2: Low/High Pass (20–400 Hz); Sub: Low Pass (50–250 Hz), Subsonic (10–50 Hz), Bass Boost 0–18 dB
Modern Vehicle Ready: Start-stop capable, high-level input via EPS cable, and auto turn-on functionality
Remote Bass Control: Includes bass level remote for precise subwoofer tuning
Safe & Reliable: Requires 60A external fuse; operates between 10.5–16.5V (briefly down to 7V)

Additional Information

Brand	Musway
Model	NX700.3
Condition	Brand New
Sold As	Single
Frequency Response	4-50000
Number of Channels	3
Amplifier Class	D
Fuse Rating	60

Channels: 3
Circuit: Digital Class D
Power @ 14.4 V (≤1% THD+N):
CH1/CH2: 2 x 85W @ 4 Ohm, 2 x 150W @ 2 Ohm, 1 x 300W @ 4 Ohm bridged
SUB: 1 x 250W @ 4 Ohm, 1 x 425W @ 2 Ohm
Frequency Range: 4 – 50,000 Hz @ -3 dB
Signal-to-Noise Ratio: > 99 dB
THD+N @ 5 W: < 0.02%
Input Sensitivity: 470 mV – 8.7 V
Filter Section CH1/CH2: Low-pass or High-pass filter 20 – 400 Hz
Filter Section SUB: Low-pass filter 50 – 250 Hz, Subsonic filter 10 – 50 Hz, Bass Boost @ 40 Hz 0 – 18 dB
Operating Voltage: 10.5 – 16.5 V (max. 5 sec down to 7 V)
Start-stop Capability: Yes
High-Level Input with EPS: Yes, via included cable connectors
Auto Turn-on: Yes, only via high-level input
Bass Level Remote Controller SUB: Yes
Fuse (External): 60 A
Dimensions: 89 x 41 x 168 mm

What's In The Box

• 3-Channel Class-D Full Range Micro Car Amplifier

• Remote Bass Control

• Owner's Manual
